ProduitsÉquipement ophtalmiqueRéfractomètreOphthalmic Refraction Chair Unit Optical
Ophthalmic Refraction Chair Unit Optical - Image 1
1 / 5
En stock

Ophthalmic Refraction Chair Unit Optical

Instruments Optometery Combination Table Optometry Unit

(4.8/5 - 24 avis)
Sur devis

Ophthalmic Refraction Chair Unit Optical Instruments Optometery Combination Table Optometry Unit

Points Clés

Measurement mode K/R mode Refractive and keratometer measure. REF mode Refractive measurement; KEF mode Corneal curvature measure; Refractive measure Vertex Distance 0.0,12.0,13.75,15.0mm; Sphere -20.00~+20.00D(0.12/0.25d Step); Cylinder 0.00~±10.00D(0.12/0.25D step)
Axis 1°~180°(1° step); Pupil Distance 30~85mm; Min.pupil diameter measurable φ2.0mm; Target Automatic fogging target; Corneal curvature measurement Radius of curvature 5~10mm(0.01mm step); Corneal Refraction 33.00~67.00D(0.12/0.25D step); Corneal Astigmatism 0.00~-15.00D(0.12/0.25D step); Angle of corneal 1°~180°(1° step); Corneal diameter 2.0~12.00mm
Hardware specification Monitor 5.7 inch color LCD; Printer Fast thermal printer; Power saving function OFF,5.15 mins(selectable); Power supply AC110~220V,50/60HZ; Dimensions/weight 288(W)*500(D)*480(H)mm/14kg; Features: 1.Using the ARM processor and the lastest domestic image processing,the system is fast and the image is clear.
2.Japan's mature optical path system,humanized automatic mist measurement process,to reduce the error caused by adjustment,more precise measurements. 3.Light rack with integral casting,CNC machining,measuring system is more stable,good consistency.
4.Color LCD display,5.7 inches man-machine interface is more comfortable. 5.PD automatic measurement function,automatically PD value. 6.One key lock function,quickly locking mobile platforms. 7.Innovative designs,accord with the structure of human body engineering,to bring customers good aesthetic feeling and comfortable. 8.With corneal curvature and dioptre measurement function. 9.Data transmission with FVT-12, improved efficiency of online

Garantie Étendue

Garantie constructeur complète

Livraison Gratuite

Installation incluse

Support 24/7

Assistance technique continue

Caractéristiques Détaillées

Ophthalmic Refraction Chair Unit Optical Instruments Optometery Combination Table Optometry Unit

Measurement mode K/R mode Refractive and keratometer measure. REF mode Refractive measurement; KEF mode Corneal curvature measure; Refractive measure Vertex Distance 0.0,12.0,13.75,15.0mm; Sphere -20.00~+20.00D(0.12/0.25d Step); Cylinder 0.00~±10.00D(0.12/0.25D step)
Axis 1°~180°(1° step); Pupil Distance 30~85mm; Min.pupil diameter measurable φ2.0mm; Target Automatic fogging target; Corneal curvature measurement Radius of curvature 5~10mm(0.01mm step); Corneal Refraction 33.00~67.00D(0.12/0.25D step); Corneal Astigmatism 0.00~-15.00D(0.12/0.25D step); Angle of corneal 1°~180°(1° step); Corneal diameter 2.0~12.00mm
Hardware specification Monitor 5.7 inch color LCD; Printer Fast thermal printer; Power saving function OFF,5.15 mins(selectable); Power supply AC110~220V,50/60HZ; Dimensions/weight 288(W)*500(D)*480(H)mm/14kg; Features: 1.Using the ARM processor and the lastest domestic image processing,the system is fast and the image is clear.
2.Japan's mature optical path system,humanized automatic mist measurement process,to reduce the error caused by adjustment,more precise measurements. 3.Light rack with integral casting,CNC machining,measuring system is more stable,good consistency.
4.Color LCD display,5.7 inches man-machine interface is more comfortable. 5.PD automatic measurement function,automatically PD value. 6.One key lock function,quickly locking mobile platforms. 7.Innovative designs,accord with the structure of human body engineering,to bring customers good aesthetic feeling and comfortable. 8.With corneal curvature and dioptre measurement function. 9.Data transmission with FVT-12, improved efficiency of online
